Manuals and User Guides for Panasonic CS-S10PKH. We have 1 Panasonic CS- S10PKH manual available for free PDF download: Service Manual. View and Download Panasonic CS-S10PKH service manual online. CS-S10PKH Air Conditioner pdf manual download. Also for: Cs-s13pkh, Cs-s15pkh. Panasonic CS-S10PKH Manual Online: Cs-s18pk Cs-s24pk. Indoor Electronic Controllers, Cross Flow Fan and Indoor Fan Motor Removal Procedures.
| Author: | Dashura Fenris |
| Country: | Senegal |
| Language: | English (Spanish) |
| Genre: | Politics |
| Published (Last): | 27 June 2016 |
| Pages: | 76 |
| PDF File Size: | 16.75 Mb |
| ePub File Size: | 18.5 Mb |
| ISBN: | 435-8-62095-768-5 |
| Downloads: | 40604 |
| Price: | Free* [*Free Regsitration Required] |
| Uploader: | Kazilmaran |
This is to provide a comfortable environment when reaching the set ON s10poh. This control will begin 1 minute after the compressor starts. The indoor unit fan stops for 90 seconds and then blows at minimum airflow for 20 seconds. The indoor unit fan stops temporarily and then starts to blow at minimum airflow for 30 seconds.
PANASONIC CS-S10PKH+H (1 TON) AIR CONDITIONER (Inverter)
Default sensitive level Sensitivity Level 5: Power supply connection to the receptacle using power plug. Fan motor can be removed after the Cross flow fan removal of cross flow fan. Outdoor fan speed can be changed to Hi or SHi according to outdoor temperature. Ipm power Transistor Prevention Control93 The final shifted value will be used as internal setting temperature and it is updated continuously whenever the electrical power is supplied to the unit.
S10pkb the CHECK button on the remote control for about 1 second with a pointed object to transmit signal to main unit. Refrigeration Cycle System In case gas leaks and accumulates at surrounding of the unit, it may cause fire.
Sunlight judgment is as following Sunlight intensity reset Judge sunlight intensity Judge ambient condition Temperature shift Piping size Torque 6. In order to achieve the suitable operation mode, the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting. High fan speed o Piping length: If wiring unit is supplied as repairing part, do not repair or connect the wire even only partial wire break.
Outdoor Air Temperature Control Do not install this appliance in a laundry room or other location where water may drip from the ceiling, etc. Cs-s10pkh Cu-s10pkh malaysia Only.
In some countries, permanent connection of this air conditioner to the power supply is prohibited. If piping s10plh is over the [piping length for additional gas], additional refrigerant should be added as shown in the table. Products powered by electricity should be serviced or repaired only by experienced professional technicians.
Figure 20 Cross Flow Fan Reminder: Outdoor high pressure rise protection Remove 4 screws holding the control board then pull out the control board. Refrigeration Cycle Diagram 5.
Panasonic CS-S10PKH Manuals
Clamp the cable so that no external force will be acted on the terminal. Low Frequency Protection Control 2 Myanmar only Power supply connection to the room air conditioner.
Electronic Circuit Diagram 8. Take care of the liquid refrigerant, it may cause frostbite. Pull out to remove the drain hose from the discharge grille Close grille door by tighten with screw and close the front panel. During operation mode judgment at the beginning of the Auto Mode operation, indoor fan motor with speed of Lo- is running for 30 seconds to detect the indoor intake air temperature. Outdoor Air Temperature Control Tighten the flare nut with torque wrench according to specified method.
Cs-s18pk Cs-s24pk – Panasonic CS-S10PKH Service Manual [Page ]
If connecting or fixing is not perfect, it will cause heat up or fire at the connection. Please check s10pky error code.
Battery insert Sensitivity Level 3: Do not use unspecified cord, modified cord, joint cord or extension cord for power supply cord.
Outdoor Unit Outdoor Unit 8. Failure to heed this caution may result in electric shocks.
Panasonic CS-S10PKH Manuals
Fix the bushing to the sleeve. Fan motor can be removed after the the unit by pulling it to the left and removal of cross flow fan.
From the above judgment, the decided operation will start operation earlier than the set time as shown below. These shifting processes are depending on the air conditioner settings and the operation environment. Table of Contents Add to my manuals Add. Do not install the unit at place where leakage of flammable gas may occur.
